High temperature tapes and masks
Distinguished by high thermal and chemical resistance, low gas emissions. Durable, cleanly removed, in one piece, without traces of stickiness after one or more heating cycles up to + 260 ° C. Thin, close to the surface, resistant to shrinkage, curling and peeling off the edges. Maintains stable dimensions at high temperatures. Meets the requirements of REACH, RoHS standards. Used for masking in the electrical, electronics, automotive, aerospace and medical industries. Used to protect printed circuit board sections by soldering, wave soldering and immersion, in the gilding process of contact wires, during comparative hot air soldering (HAL). Used for thermal insulation of electric motors and electrical insulation of components (transformers, generators, motors, motor windings and large coils). |
SKU | Summary | Price | Buy | hf:att:pa_width |
---|---|---|---|---|
8997-15-33 | Masking tape, high temperature resistant, 3M 8997 Econom, base Polyimide 30μm, amber, 15mm x 33m | €5.30 | 15mm-en | |
8997-50-33 | Masking tape, high temperature resistant, 3М 8997 Econom, base Polyimide 30μm, amber, 50mm x 33m | €17.70 | 50mm | |
8997-25-33 | Masking tape, high temperature resistant, 3М 8997 Econom, base Polyimide 30μm, amber, 25mm x 33m | €8.90 | 25mm-en | |
8997-19-33 | Masking tape, high temperature resistant, 3М 8997 Econom, base Polyimide 30μm, amber, 19mm x 33m | €6.70 | 19mm-en | |
8997-12-33 | Masking tape, high temperature resistant, 3М 8997 Econom, base Polyimide 30μm, amber, 12mm x 33m | €4.30 | 12mm-en | |
8997-9-33 | Masking tape, high temperature resistant, 3М 8997 Econom, base Polyimide 30μm, amber, 9mm x 33m | €3.20 | 9mm-en |
Characteristics:
Code | Color | The basis | Base thickness, mm | Adhesive/ thickness, mm | Operation t., (-/+,оС) | Features |
---|---|---|---|---|---|---|
8997 8998 |
Amber | PI |
0.03 0.06 |
Silicone/ 0.03 | -73 / +260 | Universal, economical heat and chemical resistant masking tapes. |
5026 | Amber | PI | Total thickness without liner 0,05 | Acrylic | -40 / + 300 | Electrical and thermal insulation for electrical components (electrical insulation according to NEMA class H). High temperature masks to protect PCB areas. Material with liner. |
5413 | Amber | PI | Total thickness 0,07 | Silicone | -73 / +260 | DuPont ™ Kapton® polyimide based tapes with silicone adhesive. High temperature masks to protect PCB areas. |
5419 | Amber | PI | Total thickness 0,07 | Silicone | -73 / +260 | 5413 analogue with anti-static adhesive. |
Showing all 6 results
Masking tape, high temperature resistant, 3M 8997 Econom, base Polyimide 30μm, amber, 12mm x 33m
€4.30 Add to cartMasking tape, high temperature resistant, 3M 8997 Econom, base Polyimide 30μm, amber, 15mm x 33m
€5.30 Add to cartMasking tape, high temperature resistant, 3M 8997 Econom, base Polyimide 30μm, amber, 19mm x 33m
€6.70 Add to cartMasking tape, high temperature resistant, 3M 8997 Econom, base Polyimide 30μm, amber, 25mm x 33m
€8.90 Add to cartShowing all 6 results
